> > > DO9 Jet / Spray Nozzle

DO9 Jet / Spray Nozzle

Key Features

Corrosion Resistant Gunmetal Construction
Easy Functionality
Twist On/Off Operation
Twist Jet / Spray Operation
Jet Only Models
Weather, Ozone & UV resistant
Low Maintenance
Available with all International Inlets

Key Users

Marine Sectors
Defence Sectors
Oil & Gas
Petrochemical Installations
Marine Industry (On and Off Shore)
Mining
Nuclear

The Delta DO9 Jet/Spray nozzle is a popular, low-cost, marine option appealing to a wide range of applications where there are corrosive, saline-rich environments. The rugged Gunmetal construction provides many years of trouble free service thanks to its highly corrosion resistant properties.

Available in three models to suit all sizes of mainline hoselines the DO9 provides simple On/Of function and selection between Jet & Spray modes by simply twisting the front barrel of the nozzle making it ideal for general purpose firefighting, washdown and dust suppression. A Jet Only option is also available.

The DO9 Type A short-pattern nozzle is supplied with either 2½” Instantaneous or 2” BSP male inlets for compatibility to any International inlet fitting. The smaller Type B model is available with 1½” Instantaneous inlet.

With flows up to 615 LPM (160 GPM) (Jet Only Model) the DO9 is incredibly versatile and excellent value for money.

The DO9 Nozzle is available in the following options:

DO9 JET ONLY NOZZLE - MARINE

Model: Jet Only - Long Pattern
Inlet: 1 1/2" Instantaneous Male
Function: Jet & Spray
Flow Range: Up to 615 LPM (160 GPM)
Product Code: NDG300002

DO9 JET / SPRAY NOZZLE - MARINE

Model: Type A - Long Pattern
Inlet: 2" BSP Male (Alternative Inlets Available)
Function: Jet & Spray
Flow Range: Up to 250 LPM (65 GPM)
Product Code: NDG210022

DO9 JET / SPRAY NOZZLE - MARINE

Model: Type A - Long Pattern
Inlet: 2 1/2" Instantaneous Male (Alternative Inlets Available)
Function: Jet & Spray
Flow Range: Up to 250 LPM (65 GPM)
Product Code: NDG200002

DO9 JET / SPRAY NOZZLE - MARINE

Model: Type B - Long Pattern
Inlet: 1 1/2" Instantaneous Male
Function: Jet & Spray
Flow Range: Up to 250 LPM (65 GPM)
Product Code: NDG050222

DO9 JET ONLY NOZZLE - MARINE

Model: Jet Only - Long Pattern (12mm Tip)
Inlet: 2 1/2" Instantaneous Male
Function: 12mm Jet Only
Flow Range: Up to 615 LPM (160 GPM)
Product Code: NDG290002

Download DO9 Technical Data Sheet

Fire Nozzle Fittings - British & International

All Delta Nozzles can be supplied with a wide range of International inlet fittings for compatibility to existing hose lines to meet the demands of our customers around the world including Instantaneous, BSP, Storz, Nakajima, Machino, Norlas, American NH, Barcelona, Gost, Rotta, Guillemin, SMS, UNI, Nunan & Stove etc.
